Features:
Input voltage 100-240V, 50/60HZ
Output voltage DC 0-10V
Matching with dimming electronic ballast and LED dimming driver
With switch, switch maximum current 3A, standard wiring port
Meet the national standard 86 panel, the size is 86*86*45mm
The connection is convenient and simple, and the rotation is smooth and flicker-free,
Product parameters:
Model number: BQ-PTDIM
Rated voltage: 100-240VAC
Frequency: 50/60HZ
Output voltage: DC0-10V
With switch: YES
Switching current: 3A.MAX
Signal current: 20mA
Working temperature: 0-60°C
Shell size: 86*86*45mm
Features:
Input voltage 100-240V, 50/60HZ
Output voltage DC 0-10V
Matching with dimming electronic ballast and LED dimming driver
With switch, switch maximum current 3A, standard wiring port
Meet the national standard 86 panel, the size is 86*86*45mm
The connection is convenient and simple, and the rotation is smooth and flicker-free,
Product parameters:
Model number: BQ-PTDIM
Rated voltage: 100-240VAC
Frequency: 50/60HZ
Output voltage: DC0-10V
With switch: YES
Switching current: 3A.MAX
Signal current: 20mA
Working temperature: 0-60°C
Shell size: 86*86*45mm
🔧 Caractéristiques techniques:
- Nom de marque: Herhe
- Produit chimique à haute préoccupation: Aucun
- Origine: CN (Origine)
- Type D’article: Gradateurs
- Garantie: 2 years
- Puissance de charge max.: 300w
- Certification: ce
📦 Informations de livraison:
- Poids: 0.200 kg
- Dimensions: 22x12x12 cm
⏱️ Délai de livraison estimé: 7 jours
